Rubber Gasket Die Cutting Machine with precision four column
| Place of Origin | JIANGSU |
|---|---|
| Brand Name | Yoyu |
| Certification | CE |
| Model Number | YY-T50 |
| Minimum Order Quantity | 1 SET |
| Price | $15000-25000 |
| Packaging Details | WOODEN CASE |
| Delivery Time | 15-20 WORKING DATES |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 20 SETS PER MONTH |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Color | Customized | Customer Logo | Accepted |
|---|---|---|---|
| Voltage | 380V | Moving Head Size | 500*500mm |
| Online Video Service | Yes | Free Spare Parts | Yes |
| Highlight | Rubber Gasket Die Cutting Machine,Sponge Insertion Cutting Machine,4 Column Gasket Die Cutting Machine |
||
Product Description
Rubber Gasket Die Cutting Machine Made In China | Sponge Insertion Cutting Machine Manufacturer
Yaoyu brand rotating head cutting machine features
1. Automatic traveling head cutting machine is widely used in a variety of industry molding die for all kinds of non-metallic materials, cutting work.
2. Double cylinder, precision four-column double crank connecting rod balance structure, to ensure that each cutting position of the same depth of the cut.
3. Unique set structure, with the cutting knife and cut the depth of the set, so that stroke adjustment is simple and accurate.
4. Cut the pressure plate to contact the cutter when the slow cut, so that the cutting of the material between the top and bottom there is no size error.
5. All the sliding parts of the central oil supply automatic lubrication system to ensure that the machine's life and accuracy.
6. Punch automatically move, easy to operate.
Parameter
| 1 | Model # | YY-T25A | YY-T25B | YY-T35A | YY-T35B |
| 2 | Cutting force | 25 Ton | 25 Ton | 35 Ton | 35 Ton |
| 3 | Working table size | 1600*500mm | 1800*500mm | 1600*500mm | 1800*800mm |
| 4 | Stroke adjustment range | 0-145mm | 0-145mm | 0-145mm | 0-145mm |
| 5 | Travelling head size | 500*500mm | 500*500mm | 500*500mm | 500*500mm |
| 6 | Hydraulic oil capacity | 110L | 170L | 270L | 270L |
| 7 | Motor power | 2.2KW | 2.2KW | 3KW | 3KW |
| 8 | Voltage | 380V 50HZ | 380V 50HZ | 380V 50HZ | 380V 50HZ |
| 9 | Machine size(mm) | 2250*650*2050 | 2490*650*2050 | 2250*650*2050 | 2490*650*2050 |
| 10 | Package size(mm) | 2300*700*2100 | 2550*700*2100 | 2550*700*2100 | 2550*700*2100 |
| 11 | Net weight | 1300kgs | 1650kgs | 1300kgs | 1650kgs |
| 12 | Gross weight | 1550kgs | 1900kgs | 1600kgs | 1900kgs |
More Machine Pictures
FAQ
1)What's warranty of machine?
12 months Warranty
Life-long maintenance service for machine
2)What's your after-sales service?
Engineer available to serve machines overseas;
Email and calling service in working hour; 24 hours door to door in domestic.
3)Can you test cutting our material by your machine for free?
Yes, please contact us and send your material.
4)How to decide how much ton pressure is needed?
Normally one meter of knife line needs about 5 tons cutting pressure.
please send your drawing or product photo, we can help you confirm.
5)Can you make dies & PP boards?
Yes, just send your drawing or requirements.
6)Are you a factory or trading company?
We are a factory and manufacturer
7)Don't know which machine is suitable for your material?
Please provide below information to us !
| Material: | |
| Max. material width: | |
| Max. material thickness: |
